Inconel 600 / AMS 5540 / ASTM B168

Phone : +86 13791102120

WhatsApp : +86 13791102120

Email : admin@dongtesteelgroup.com

Product Description

ASTM B168 specification covers rolled plates, sheets, and strips made of nickel-chromium-iron alloys. Inconel 600 Plate is a Nickel-Chromium-Iron alloy with good corrosion resistance, oxidation resistance, and high strength at high temperatures. Alloy 600 can operate from cryogenic temperatures to 700°F.

Inconel 600 Plate Sheet Specifications

Specification	ASTM B168 / ASME SB 168, AMS 5540, AMS 5665
Dimensions	Cold rolled 0.5-6.4 mm
Dimensions	Hot rolled 3.0–10.0 mm
Thickness	0.1 to 100 mm Thk
Width	10-2500mm
Length	2m, 2.44m, 3m, or as required
Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard
Form	Plate, Coils, Sheet, Strip, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate

Nickel Inconel 600 Plate Chemical Composition

Weight%	C	S	Cr	Cu	Mn	Si	Ni	Fe
Nickel Alloy 600	0.15 max	0.015 max	14.0 - 17.0	0.50 max	1.0 max	0.50 max	72.0 min	6 - 10

Alloy 600 Plate Mechanical Properties

Material	Form and Condition	Tensile Strength		Yield Strength		Elongation %	Hardness, Rockwell
Material	Form and Condition	ksi	MPa	ksi	MPa	Elongation %	Hardness, Rockwell
Alloy 600 Plate	Hot rolled Annealed	80-100	550-725	30-50	205-345	55-35	65-85B
Alloy 600 Sheet	Cold Rolled Annealed	80-100	550-690	30-45	205-310	55-35	88B max
