Product Description

2.4375 is a nickel-copper alloy which combines the excellentcorrosion resistance of MONEL alloy 400 with the added advantages of greater strength and hardness. The increased properties are obtained by adding aluminum and titanium to the nickel-copper base, and by heating under controlled conditions so that submicroscopic particles of Ni3(Ti, Al) are precipitated throughout the matrix. The thermal processing used to effect precipitation is commonly called age hardening oraging.

Chemical composition

Chemical elementCMnSiSNiCuFeAlTiCo
Minimum value %----63%27%-2,3%0,35%-
Maximum value %0,25%1,5%0,5%0,01%-33%2%3,15%0,85%2%

Mechanical properties

ConditionSubtypeRm [N/mm²]Rm [Ksi]Rp0,2% [N/mm²]Rp0,2 % [Ksi]E4D [%]HBW
Cold Worked - AgedCW-PH970 min141 min690 min100 min14 min-
Cold Worked - Solution Annealed and AgedCW
A + PH		900 min131 min585 min85 min20 min-
Hot Worked - Solution AnnealedHW - A-----185 max
Hot Worked - AgedHW - PH830 min120 min550 min80 min15 min-
Hot Worked - Solution Annealed and AgedHW A+PH830 min120 min500 min73 min15 min-

Applications of monel K-500 material

Monel K-500 material is used in sea water, offshore engineering, in the chemical process and petrochemicals industry and shipbuilding.
Typical applications are:
  • Valve seals, pump sleeves and wearing rings in sea water
  • Pump shafts and propeller shafts
  • Mounting elements/fasteners, e.g. bolts in sea air and splash water zones
  • Tug rope armoring
  • Springs
  • Components of drilling equipment in the oil industry
  • Aircraft instrument components
