Monel K500 bars are an extremely corrosion resistant nickel-copper alloy known for its superior corrosion resistance, high strength, and long service life. Made up primarily of nickel and copper with smaller amounts of elements such as iron and manganese incorporated, Monel K500 bars can often be seen used in marine environments, chemical processing equipment and aerospace applications due to its ability to resist seawater, acids and alkalis.
Monel K500 bars are known for their superior corrosion resistance, making them suitable for use in harsh environments like marine and chemical processing industries. Monel's resistance to various corrosive agents such as seawater, acids and alkalies, ensures lasting reliability even under demanding circumstances.
Monel K500 Bars Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | BS | AFNOR | EN |
| Monel K500 | 2.4375 | N05500 |
|
|
|
|
|
Chemical Composition of Monel K500 Bars
| Grade | C | Mn | Si | Cu | Fe | Ni | S |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min | 0.010 max |
Mechanical Properties of Monel K500 Bars
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15000 , MPa – 790 | 20% |
Monel K500 Bars Applications
- Centrifugal pumps
- Valve & shaft components
- Pump shafts & impellers
- Chains
- Cables
- Fasteners
- Springs
